模数转换器（ADC）
9888拉斯维加斯提供的模数转换器(ADC)产品，为各类利用提供更高的转换精度、更快的转换速度以及更低的功耗 。该系列ADC模数转换器产品蕴含逐次逼近（SAR）和Sigma Delta两种架构，为工业、能源和消费类等分歧领域的利用提供矫捷的选择 。
产品选择器
10 个了局
Loading
|
Part No
|
Status
|
Analog Supply (V)
|
Digital Supply (V)
|
Channel
|
Resolution (bit)
|
Max Smpling Rate(KSPS)
|
Input Range(V)
|
SNR(dB)
|
THD (dB)
|
INL (LSB)
|
Power (mW)
|
Interface Type
|
Operating Temperature Range(°C)
|
Package
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MP | 4.5~5.5 | 1.71~5 | 8 | 16 | 500 | +/-12.5V, +/-10V +/-5V, +/-2.5V | 91 | -105 | +/-1 | 53 | SPI / Parallel | -40~125 | LQFP64 | |
| MP | 4.5~5.5 | 1.71~5 | 8 | 16 | 1000 | +/-12.5V, +/-10V +/-5V, +/-2.5V | 91 | -105 | +/-1 | 53 | SPI / Parallel | -40~125 | LQFP64 | |
| MP | 4.5~5.5 | 1.71~5 | 16 | 16 | 1000 | +/-10V +/-5V, +/-2.5V | 90.5 | -102 | +/-1 | 160 | SPI / Parallel | -40~125 | LQFP80 | |
| MP | 4.5~5.5 | 1.71~5 | 16 | 16 | 1000 | +/-10V +/-5V, +/-2.5V | 90.5 | -102 | +/-1 | 160 | SPI / Parallel | -40~125 | LQFP80 | |
| MP | 4.5~5.5 | 1.8~5.8 | 8 | 16 | 250 | SE: 0~4.096 Diff: +/-2.048 | 90.5 | -110 | +/-0.5 | 12.5 | SPI | -40~105 | QFN20 | |
| MP | 4.5~5.5 | 1.8~5.8 | 8 | 16 | 500 | SE: 0~4.096 Diff: +/-2.048 | 90.5 | -110 | +/-0.5 | 26 | SPI | -40~105 | QFN20 | |
| MP | 2.2~5.5 | NA | 4 SE, 2 Diff | 16 | 1 | +/-0.064~+/-6.144 | NA | NA | +/-8ppm/FS | 0.9 | I2C | -40~125 | MSOP10 | |
| MP | 2.2~5.5 | NA | 4 SE, 2 Diff | 16 | 1 | +/-0.064~+/-6.144 | NA | NA | +/-8ppm/FS | 0.9 | SPI | -40~125 | MSOP10 | |
| MP | 2.7~5.5 | NA | 4 SE, 2 Diff | 24 | 1 | +/-0.064~+/-6.144 | NA | NA | +/-8ppm/FS | 0.9 | I2C | -40~125 | MSOP10 | |
| MP | 2.7~5.5 | NA | 4 SE, 2 Diff | 24 | 1 | +/-0.064~+/-6.144 | NA | NA | +/-8ppm/FS | 0.9 | SPI | -40~125 | MSOP10 |
